OPTO-EDU A13.2607 Invered MetallInvered Metallurgical Microscope, BF,PL

Product Categories

Opto-Edu (Beijing) Co., Ltd.

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Name: OPTOEDU A132607 Invered MetallInvered Metallurgical Microscope BFPL
Brand: CNOEC, OPTO-EDU
Price: 1 USD

Place of Origin : China

Brand Name : CNOEC, OPTO-EDU

Certification : CE

Model Number : A13.2607

MOQ : 1 pc

Price : FOB $1~1000, Depend on Order Quantity

Packaging Details : Carton Packing, For Export Transportation

Delivery Time : 5~20 Days

Payment Terms : T/T, West Union, Paypal

Supply Ability : 5000 pcs/ Month

Head : "Swiveling Siedentopf, Inclined 45°, IPD: 48-75mm,Light distribution: 70:30（70% For Eyepiece, And 30% For Camera Tube）"

Eyepiece : WF10X/20mm, High Eyepoint

Nosepiece : Quadruple

Mechanical Stage : Three-layer Working Stage, Stage size: 180×155mm, Moving Range:75×40mm, Scale: 0.1mm, Round Slide Size：φ110mm

Focusing : Coaxial Coarse And Fine, Coarse Stroke: 10mm, Fine Stroke PerRrotation: 0.2mm, Fine Division 2 μm.

Polarizing Unit : Polarizer, Analyzer

llumination : 5W LED Warm Lamp,

Filter : Grey

C-mount : 0.65×C-Mount, Built-in

Holder : Universal Holder for HD Screen

Contact Now

Invered Metallurgical Microscope, BF,PL

Items	A13.2607 Inverted Metallurgical Microscope
Head	Swiveling Siedentopf, Inclined 45°, IPD: 48-75mm,Light distribution: 70:30(70% For Eyepiece, And 30% For Camera Tube)	●
Eyepiece	WF10X/20mm, High Eyepoint	●
Eyepiece	WF10X/20mm, High Eyepoint, Adjustable Focus, Reticule 0.1mm	●
LWD Infinity Plan Objectives	LPL 5×／0.13, W.D=16.04mm	●
	LPL 10×／0.25, W.D.= 18.48mm	●
	LPL 20×／0.40, W.D.= 8.35mm	●
	LPL 50×／0.70, W.D.= 1.95mm	●
	LPL 80×／0.80, W.D.= 0.85mm	○
	LMPlan FL 100×／0.85(Dry), W.D.= 3.00mm	○
Nosepiece	Quadruple	●
Mechanical Stage	Three-layer Working Stage, Stage size: 180×155mm, Moving Range:75×40mm, Scale: 0.1mm, Round Slide Size:φ110mm	●
Focusing	Coaxial Coarse And Fine, Coarse Stroke: 10mm, Fine Stroke PerRrotation: 0.2mm, Fine Division 2 μm.	●
Polarizing Unit	Polarizer, Analyzer	●
llumination	5W LED Warm Lamp, Powered By Safety Low Voltage Charger, Input Wide Voltage 100V-240V, Output 5V1A, Support Power Bank Supply For Outdoor Use	●
Filter	Grey	○
C-mount	0.65×C-Mount, Built-in	●
Holder	Universal Holder for HD Screen	○
HDMI Camera	With Measurement Function	○
HD Screen	10.1” HD LCD	○
Packing Size: 500mm×425mm×305mm Gross Weight:9.0 kgs Net Weight: 7.0 kgs
Note: "●"In Table Is Standard outfits, "○" Is Optional Accessories.

OPTO-EDU A13.2607 Invered MetallInvered Metallurgical Microscope, BF,PL
